Nintendo 64 THS7374 RGB Amp CSYNC

£17.99 £14.99 excl. VAT

High quality N64 Nintendo 64 RGB mod kit for NTSC (USA or JP) consoles. Output properly attenuated RGB from your N64!

Features:

  • Uses the latest THS7374 amp by Texas Instruments which offers a sharper image over the previous THS7314.
  • Low-pass filter toggle with JP1.
  • Professionally assembled using high-quality components from JP & USA. Brands such as Nichicon, Vishay, Panasonic.
  • Premium ENIG (gold immersion) finish.

Install instructions (please also see notes below): https://github.com/TzorriMahm/N64_RGB_Amp

Compatibility warning: Only compatible with NUS-CPU-01/02/03/04 main board revisions! Also, please verify that your main board has a ‘VDC-NUS’/’VDC-NUS A’ chip (U4).

In stock

SKU: RGB-MOD-N64 Categories: , Tags: , , , ,

Description

Included: – Fully assembled N64 RGB amp PCB.
– High quality wires suitable for AV modifications. Sufficient length provided for one installation.

Use this board to save yourself from badly designed & cheap boards which can commonly have issues such as ghosting, artifacts and bad compatibility with scalers.

The amp is configured for use with a standard NTSC SNES CSYNC cable (with 470Ω resistor in SCART head).

As per the install guide, please remember to isolate the bottom side of the board to avoid any shorts!

*Difficulty level is the opinion of Retro Upgrades. This kit is sold as DIY and requires soldering skills, please review the documentation and make sure you are confident in installing this kit prior to purchasing!
